FEATURES
- Multilingual operation
- Automatic built in test and self diagnosis
- Secure access key
- Uninterruptable power supply for computer
- Treat alert and material classification
- Auto archiving
- Energy saving design
- Indication of the date and time
- One key turn off
- Drugs and explosive inspection
SPECIFICATIONS
Unit weight: 260 Kgs
Unit size: 1660(L)x746(W)x1165(H)
Gross weight:
400kg
Packing size:
179x87x137cm
Tunnel size:
500(L)x300(W)
Conveyor speed: 0.22m/s
Conveyor height: 663mm
Conveyor max load:
100kg
Penetration: 8mm steel
Wire resolution:
dia 0.0787mm copper wire (AWG40)
Penetration resolution: dia 0.202mm copper wire (AWG32) under three-step aluminum wedge 9.5mm, 15.9mm, 22.2mm
Power consumption:
max 500W
Noise: <60dB
X-RRAY GENERATOR (SINGLE)
Anode voltage:
140KV
Ray direction: Upward
Cooling / Duty Cycle: Sealed oil cooling / 100 %
IMAGE SYSTEM
X-Ray sensor:
L-shaped photodiode array, 12bit deep
Image process: 24bit real time processing, 4-color analysis, ID No., counts the number of bags.
Image display: 1024x1280 pixel; Image gray level: 4096
Image enhancement: 1-64 times enlargement continuity, color/BW, negative, high/low penetration enhancement, brightening, darkening, gray level scan, super enhancement, elimination of organics/inorganics, local enhancement, pseudo color processing, edge enhancement, etc.
Explosives & narcotic detection: Suspicious organics highlight.
Suspicious alarm: Alarm and box lines the suspicious objects including hard to penetrate material, explosives, and drugs.
Threat Image Projection: Inserting fictional but realistic images of threat items into the baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability.
Image recall: 30 images recallable
Image archive: Up top 10,000 images stored automatically, enable transferring to USB disk, and converting to jpg, bmp, and other general formats.
Options: Multiple remote applications available based on Ethernet LAN and windows platform.
OPERATING ENVIRONMENT
Operation temperature/ humidity: 5-40 / 0%-90% (non-condensing)
Storage temperature/ humidity: -20-60 / 10%-90% (non-condensing)
Operation Power: 220VAC (±10%) 50±3Hz (Optional: 100VAC, 110VAC, 120VAC, 2000VAC)
UPS: Options: 15mins, 30mins, 60mins
COMPUTERS AND OTHERS
Monitor:
High resolution color, 1280x1024 LCD Accord, 17in
RAM:
1GB
Hard Disk:
500G
Keyboard: Special design
System: Embedded Linux operating system, multi core ARM, stable and reliable
Electric roller: Single-phase
COMPLIANCE
International: ISO19001, ISO14001, OHSMS18001
